306
N. Kojima and A. Okazawa
The
57 Fe Mossbauer spectrum at room temperature shows an asymmetric doublet
with much broadening in order to a magnetic relaxation, where the IS of ~0.4 mm/s
and the QS of 1.3 mm/s. The temperature-independent characteristics of quadrupole
splitting is observed, indicating a large separation between the ground orbital states
and the excited ones. Below about 50 K, the broad doublet becomes a well-resolved
sextet, and then ends up with the sharp spectrum having overall hyperfine splitting
of 48.8 mm s
−1 at 4.2 K. The result indicates slower magnetization relaxation than
the Mössbuaer time scale (τ ~ 10
−8 s). Magnetic hyperfine field, H n , is estimated as
152 T. According to H n = H F + H D + H L , where H F is the Fermi contact roughly
determined by −12.7 × (2S) T [69] and H D is the dipolar contribution, the value of
the orbital contribution term, H L , is estimated as 203 T when H D is assumed to be
zero.
In the precedent paper [70], saturation magnetization of this compound was
reported to reach ~32,500 cm
3 Oe mol
−1 (or 5.82 μ B ) at 1.85 K (for field-oriented
sample), which is larger than the spin-only value (4 μ B ) that would be expected for the
Fe
II ion with S = 2. After this preliminary study, the details of dynamic magnetization
in the SIM compound have been examined by means of ac and dc magnetic property
measurements and ab initio calculations [71], followed by the analysis of
57 Fe Mössbauer relaxation spectra [72]. Low-temperature saturation magnetization for a fixed
sample of [Fe(C(SiMe 3 ) 3 ) 2 ] is of M sat = 3.24 μ B . This value is lower than the spinonly value of the HS Fe
II ion because of random orientation of strong anisotropic
species. Actually, the χ M T value at room temperature is 4.79 cm
3 K mol
−1 (the effective magnetic moment: μ eff = 6.19 μ B ), indicating strong anisotropy with a large g
value of 2.53. At zero applied dc field, [Fe(C(SiMe 3 ) 3 ) 2 ] shows no slow relaxation of
magnetization in ac magnetic susceptibility, indicating no SIM behavior. However,
such a relaxation can be detectable by means of
57 Fe Mössbauer spectroscopy as
shown in Fig. 6.40, and analysed using a relaxation model formalized by Dattagupta
and Blume [73]. Relaxation time constant (τ ) ranges from 2.5 × 10
−7 to 1.2 ×
10
−10 s within the measuring temperature range of 5–295 K. From the analysis of
Arrhenius plots, the physical parameters on quantum tunnelling and Orbach relaxation processes were extracted as τ
−1
QTM = 4.2(3) × 10
6 s
−1 and U eff = 178(9) and
553(68) cm
−1 , respectively. Two obtained U eff values correspond to the energy splitting from the ground M J = ±4 to the first excited M J = ±3 or the second excited
M J = ±2 doublets among the Stark sublevels of
5 D 4 . It should be mentioned that
ac susceptibility measurements (τ < ~10
4 s) cannot detect the magnetic relaxation
for this system due to the fast QTM process (τ QTM = 2.4 × 10
−6 s) at the level
crossing between the ground M J = ±4 states under zero field. Applying a small dc
field induced suppression of the level crossing between the M J doublets, and thus
magnetization dynamics was observable as a nonzero signal in the out-of-phase ac
susceptibility (χ M
). For Cole–Cole plots, the relaxation dynamics can be evaluated by using a generalized Debye model [74, 75]. Their results reveal clearly the
field-induced SIM nature of [Fe(C(SiMe 3 ) 3 ) 2 ].
Following the pioneering compound, some of ca. 30 linear two-coordinate
Fe
II complexes [76] have currently been investigated from the viewpoint of SIM
