in the third layer of D-type triggers, final operations of the required function are
performed:
V5: f = Q
∗
¯
a ∧ b ∧ ¯
a ∧ ¯
b = a ∧ b ∨ ¯
a ∧ ¯
b;
V6: f = ¯
Q
∗
= ¯
a ∧ b ∧ a ∧ ¯
b = ¯
a ∧ b ∨ a ∧ ¯
b.
Such building of circuits is characterized by the fact that all logic gates of a single
layer of all triggers are switched at the same points in time relative to the common
LSIC clock signal.
In generalized form, the above rules of designing such protected ICs can be briefly
formulated as follows:
– Basic elements are the conjunctor, the inverter, and the non-symmetrical D-trigger
(Fig. 6.109);
– Chains between D-triggers during operation at a frequency can include sequences
of not more than (i + 1) gates;
– It is possible to expand functional possibilities of triggers by increasing the number
of D-inputs and distributing operations of logic functions over time layers of the
D-trigger (zero, first, second, and third) on condition of strict compliance with
the recommended points of connection of control information.
The above technical solutions were implemented in the reverse engineeringprotected microcircuits of the LSIC set for digital handling of signals, which is
designed to be used in control systems of phased antenna arrays (PAA).
