116
G. Avoine et al.
7.2.1 Basic Relay Strategies
A basic relay equates to the attack described in Sect. 7.1.
7.2.1.1 Purpose-Built Relays
There are several relay-attack implementations against radio frequency identification (RFID) systems using purpose-built attack proxies and relay links, which
incur minimal delay in executing the attack, e.g., [221, 256, 548]. The conventional
approach to implementing an attack uses custom-built attack proxies, using a
combination of custom hardware and hacked readers [256, 548]. The proxy will first
demodulate the data symbols from the reader or token, and then forward data over
an analog radio link, e.g., a video channel [256], and this tends to introduce a delay
in the order of a few to tens of microseconds (2–20 µs). These implementations are
also capable of active relay attacks, equivalent to a conventional man-in-the-middle
or ‘wedge’ attack, which can modify communication with negligible additional
delay, e.g., using an FPGA to reshape analog signals in real-time [256]. If the goal
is to minimize the relay delay to less than a microsecond then the relay link can
be implemented without demodulating the data first [221, 548]. In these cases, the
proxies are either connected via a wire (120–500 ns delay), or forward data by direct
up-mixing of the LF/HF carrier onto a UHF radio carrier for transmission (120–
750 ns delay).
7.2.1.2 Off-the-Shelf Relays
It has also been shown that software-only implementations using off-the-shelf
NFC-enabled mobile devices are effective, which simplifies the attack and allows
any person with the right type of NFC-enabled mobile phone to implement a
token emulator or a reader. These attacks can therefore use a standard phone as
a proxy-reader and a second phone as a proxy-token and relay the data across
Bluetooth, WiFi or the mobile data network [222, 392, 539]. Even though such
attack implementations incur a larger attack delay (200-500 ms), these remain
effective against real systems, as was demonstrated in an attack against Google
Wallet [505]. There are an increasing number of non-mobile NFC devices, such
as the Adafruit NFC breakout board, that easily connects with embedded hardware
Arduino or Raspberry Pi, which could be used as readily available proxy platforms.
