5 Commercial Aspects of Biomass Deconstruction with Ionic Liquids
89
liquid instead of the conventional amine process provided key advantages due to
the nucleophilic catalytic activity of 1-alkylimidazole that increased the space-time
yield (STY) by a factor of 86,000 as well as the economic reclamation of the 1alkylimidazole by IL deprotonation [20, 21]. Such a remarkable improvement in
process performance was crucial to accelerate the industrial deployment of new solvents, such as ILs. Likewise, the application of an IL-based pretreatment process
will have to feature exclusive selling points and key processing advantages for it
to compete with processes of similar or higher technology readiness level. From a
high-level perspective, the key advantages of IL-based pretreatment compared to
peer technologies include: (1) low operating pressure and reduced solvent losses
as ILs are non-volatile solvents, (2) potentially lower capital cost of a pretreatment
reactor compared to aqueous or organic solvent due to ILs’ non-volatile nature, [22]
(3) lower enzymes loading and smaller operation units due to lignin pre-extraction
during pretreatment, [23] (4) production of high-quality lignin of high valorization
potential, [24] and (5) robust process performance that is highly independent of
feedstock type and composition [25–28].
Despite these appealing advantages, the very high cost of ILs compared to aqueous
or organic solvents has been always highlighted as the key barrier for their large-scale
application [29].
However, it was only recently demonstrated that the high cost associated with
ILs is not inherent, but it is a consequence of choosing historically dominant ILs
(dialkylimidazolium cations with poly-fluorinated anions) [30]. Overcoming the IL
cost barrier was the key turning point that enabled the discussion of ionoSolv’s
potential commercialization.
5.1.1 Technology Readiness Level
The path of translating academic research to a large-scale industrial process follows
several validation and development steps. Technology readiness level (TRL) is a
popular concept adapted in several sectors (e.g., space, defence, and oil and gas
operations) to measure technology maturity level and its readiness for large-scale
deployment. The scale and definition are slightly different to suit the requirement of
the different sectors; however, they all have the same general structure and pathway
starting from proof of concept and lab experiments to pilot testing and demonstration
and eventually to a mature industrially proven technology. Figure 5.1 shows the TRL
scale and definition according to the 2017 European Commission, which can be used
for renewable energy technologies [31]. In the context of this chapter, TRLs from
1 to 7 were used to describe the development pathway of using ILs for biomass
pretreatment with special focus on our own experience in the development of the
ionoSolv process.
