Reference_01
24.2g
-Shear/tensile
core failure
- Face sheet
rupture
Reference_02
24.6g
-Shear/tensile
core failure
- Face sheet
rupture
Reference_03
24.3g
-Shear/tensile
core failure
- Face sheet
rupture
Hourglass_01
30.9g
- Core shear
failure
- Screw shear
off
Hourglass_02
30.6g
- Core shear
failure
- Debonding
of insert
Hourglass_03
31.9g
- Core shear
failure
- Insert rupture
Undercut_01
30.2g
-Shear/tensile
core failure
- Face sheet
rupture
Undercut_02
37.5g
- Core shear
failure
- Insert rupture
Undercut_03
33.1g
- Core shear
failure
- Insert rupture
0
1
2
3
4
5
0
500
1000
1500
2000
2500
3000
Displacement [mm]
Force [N]
Reference_01
Reference_02
Reference_03
0
2
4
6
0
500
1000
1500
2000
2500
3000
Displacement [mm]
Force [N]
Hourglass_01
Hourglass_02
Hourglass_03
0
1
2
3
4
5
0
500
1000
1500
2000
2500
3000
Displacement [mm]
Force [N]
Undercut_01
Undercut_02
Undercut_03
