Appendix A – Constituent level
3D-continuum models
_______________________________________________________________________
Elasto perfectly plastic material according to the manufacturer’s data sheet
*MATERIAL, NAME= NOMEX_SOLID_MANUFACTURER
*ELASTIC, TYPE=ENGINEERING CONSTANTS
1, 1, 137, 0.01, 0.01, 0.01, 0.1, 40,
25
*DENSITY
4.8e-11
*PLASTIC, HARDENING = ISOTROPIC
2.2, 0.0
*POTENTIAL
1,1,1,1,1,0.5
_______________________________________________________________________
Calibrated plastic material according to the experimental results
*MATERIAL, NAME= NOMEX_SOLID_CALIBRATED
*ELASTIC, TYPE=ENGINEERING CONSTANTS
1, 1, 137, 0.01, 0.01, 0.01, 0.1, 38,
22
*DENSITY
4.8e-11
*PLASTIC, HARDENING = ISOTROPIC
2.15, 0.0
2.15, 0.020
1, 0.05
1, 0.2
0.001 , 0.7
0.0001, 0.9
*POTENTIAL
1,1,1,1,1,0.48
_______________________________________________________________________
