List of Figures
Figure 4.2 Corrosion products formed on zinc during atmospheric
exposure .............................................................................................................. 107
Figure 4.3 Potential-pH diagram, Al-H 2 O; 25°C, 10 −1 M Al .................... 117
Figure 4.4 Maximum pit depth vs. exposure time for Al Mn 1.2 in
an urban atmosphere ......................................................................................... 118
Figure 6.1 Butt welding preferred rather than lap welding or
riveted construction ...........................................................................................172
Figure 6.2 Remove all weld spatter and grind smooth ........................... 173
Figure 6.3 Avoid all pockets or crevices that cannot be properly
sandblasted and lined ....................................................................................... 173
Figure 6.4 All joints must be continuous solid welded and ground
smooth ................................................................................................................. 174
Figure 6.5 Grind all sharp edges to a minimum 1/8-in. radius ............. 174
Figure 6.6 Typical vessel outlets ................................................................. 175
Figure 6.7 Stiffening members should be on the outside of the
vessel .................................................................................................................... 175
Figure 6.8 Potential galvanic action ........................................................... 176
Figure 7.1 Bonding situation at the interface of polymer layer and
substrate .............................................................................................................. 212
Figure 7.2 (a) Mechanical, (b) thermal, and (c) chemical bond failure .. 213
Figure 7.3 Blister initiation and propagation under a defective
coating (cathodic delamination) ...................................................................... 216
Figure 7.4 (a) Anodic and (b) cathodic electrodeposition of paints .......236
Figure 8.1 Structure of the corrosion cell ..................................................256
Figure 8.2 Mechanism of the corrosion cell ..............................................257
Figure 8.3 Activation and concentration overpotentials in a typical
corrosion process ................................................................................................259
Figure 8.4 Four types of corrosion controls ..............................................263
Figure 8.5 Data showing that the fractional exposed area of copper
in a copper-gold system is linearly related to the corrosion potential at
low exposed copper areas .................................................................................266
Figure 8.6 Dissolution of substrate metal in coating defect .................... 267
Figure 8.7 Effect of sulfur content on corrosion protection of nickel ....268
