Access Data in Nested Structures
This example shows how to index into a structure that is nested within another structure. The general
syntax for accessing data in a particular field is
structName(index).nestedStructName(index).fieldName(indices)
When a structure is scalar (1-by-1), you do not need to include the indices to refer to the single
element. For example, create a scalar structure s, where field n is a nested scalar structure with
fields a, b, and c:
s.n.a = ones(3);
s.n.b = eye(4);
s.n.c = magic(5);
Access the third row of field b:
third_row_b = s.n.b(3,:)
Variable third_row_b contains the third row of eye(4).
third_row_b =
0
0
1
0
Expand s so that both s and n are nonscalar (1-by-2):
s(1).n(2).a = 2*ones(3);
s(1).n(2).b = 2*eye(4);
s(1).n(2).c = 2*magic(5);
s(2).n(1).a = '1a';
s(2).n(2).a = '2a';
s(2).n(1).b = '1b';
s(2).n(2).b = '2b';
s(2).n(1).c = '1c';
s(2).n(2).c = '2c';
Structure s now contains the data shown in the following figure.
Access part of the array in field b of the second element in n within the first element of s:
part_two_eye = s(1).n(2).b(1:2,1:2)
This returns the 2-by-2 upper left corner of 2*eye(4):
part_two_eye =
2
0
0
2
See Also
struct | setfield | getfield
