+k3b = 11.372
w0 = 1.4976e-008
dvt0 = 0.030258
+dvt1 = 0.27353
dvt2 = -0.1292
dvt0w = 0
+dvt1w = 10000000
dvt2w = 0.01
dsub = 0.079604
+minv = 0.57893
voffl = -3.2236e-015 dvtp0 = 0
+dvtp1 = 0
lc = 5e-009
lambda = 0
+vtl = 200000
lpe0 = 0
lpeb = 9.7128e-009
+vbm = -3
xj = 5.81e-008
ngate = 1.1557e+021
+ndep = 1.7e+017
nsd = 1e+020
phin = 0
+cdsc = 0.00038013
cdscb = 0.00029951
cdscd = 0
+cit = 0.00029514
voff = -0.091517
nfactor = 4.6201
+eta0 = 0.00011433 etab = -0.00018655 u0 = 0.053874
+ua = 1.3724e-009
ub = 2.4451e-021
uc = -0.3327
+eu = 1.67
vsat = 81402
a0 = 4.034
+ags = 0.51
a1 = 1e-005
a2 = 1
+b0 = 6.0098e-015
b1 = 0
keta = 0.010603
+lketa = 0.0030012 dwg = 0
dwb = 0
+pclm = 0.26825
lpclm = 0.0057
pdiblc1 = 0.030607
+pdiblc2 = 2.582e-005 pdiblcb = 0.01
drout = 1.1625
+pvag = 0
delta = 0.0045611
ldelta = 0.0002262
+pscbe1 = 1.1753e+009 pscbe2 = 1e-005
fprout = 0.01
+pdits = 0
pditsd = 0
pditsl = 0
+rsh = 0
rdsw = ‘159.72+drdswn_svt’
+rsw = 100
rdw = 100
rdswmin = 0
+rdwmin = 0
rswmin = 0
prwg = 0.15293
+prwb = 0.080695
wr = 1
alpha0 = 0
+alpha1 = 0
beta0 = 30
agidl = 2.6078e-010
+bgidl = 4984400
cgidl = 1974.8
egidl = 0.057969
+aigbacc = 0.43
bigbacc = 0.054
cigbacc = 0.075
+nigbacc = 1
aigbinv = 0.35
bigbinv = 0.03
+cigbinv = 0.006
eigbinv = 1.1
nigbinv = 3
+aigc = 0.43
bigc = 0.054
cigc = 0.075
+aigsd = 0.43
bigsd = 0.054
cigsd = 0.075
+nigc = 1
poxedge = 1
pigcd = 1
+ntox = 1
*************************************************************
*
CAPACITANCE PARAMETERS
*************************************************************
+cgso = ‘cgon_svt’ cgdo = ‘cgon_svt’
cgbo = 2.191e-009
+cgdl = ‘cgln_svt’ cgsl = ‘cgln_svt’
clc = 2.905e-010
+cle = 1
ckappas = 0.6
ckappad = 0.6
+vfbcv = -1.1698
acde = 0.37365
lacde = -0.00145
+moin = 3.8485
lmoin = 0.022
noff = 2.118
+lnoff = 0.0114
voffcv = 0.048569
lvoffcv = 0.00012324
*************************************************************
*
TEMPERATURE PARAMETERS
*************************************************************
+kt1 = -0.38457
kt1l = -9.0624e-012
kt2 = -0.029313
+ute = -2.895
ua1 = 1.4986e-009
ub1 = -3.2473e-018
