Table 5.2
(continued)
Press., Sat. temp., Specific volume, m
3
/kg Internal energy, kJ/kg
Enthalpy, kJ/kg
Entropy, kJ/kg
Á K
Sat. liquid, Sat. vapour, Sat. liquid, Evap., Sat. vapour, Sat. liquid, Evap., Sat. vapour, Sat. liquid, Evap., Sat. vapour,
P
kPa
T
sat °C
v
f
v
g
u
f
u
fg
u
g
h
f
h
fg
h
g
s
f
s
fg
s
g
1300
191.60
0.001144
0.15119
813.10
1776.8 2589.9
814.59
1971.9 2786.5
2.2508
4.2428 6.4936
1400
195.04
0.001149
0.14078
828.35
1763.4 2591.8
829.96
1958.9 2788.9
2.2835
4.1840 6.4675
1500
198.29
0.001154
0.13171
842.82
1750.6 2593.4
844.55
1946.4 2791.0
2.3143
4.1287 6.4430
1750
205.72
0.001166
0.11344
876.12
1720.6 2596.7
878.16
1917.1 2795.2
2.3844
4.0033 6.3877
2000
212.38
0.001177
0.099587 906.12
1693.0 2599.1
908.47
1889.8 2798.3
2.4467
3.8923 6.3390
2250
218.41
0.001187
0.088717 933.54
1667.3 2600.9
936.21
1864.3 2800.5
2.5029
3.7926 6.2954
2500
223.95
0.001197
0.079952 958.87
1643.2 2602.1
961.87
1840.1 2801.9
2.5542
3.7016 6.2558
3000
233.85
0.001217
0.066667 1004.6
1598.5 2603.2
1008.3
1794.9 2803.2
2.6454
3.5402 6.1856
3500
242.56
0.001235
0.057061 1045.4
1557.6 2603.0
1049.7
1753.0 2802.7
2.7253
3.3991 6.1244
4000
250.35
0.001252
0.049779 1082.4
1519.3 2601.7
1087.4
1713.5 2800.8
2.7966
3.2731 6.0696
5000
263.94
0.001286
0.039448 1148.1
1448.9 2597.0
1154.5
1639.7 2794.2
2.9207
3.0530 5.9737
6000
275.59
0.001319
0.032449 1205.8
1384.1 2589.9
1213.8
1570.9 2784.6
3.0275
2.8627 5.8902
7000
285.83
0.001352
0.027378 1258.0
1323.0 2581.0
1267.5
1505.2 2772.6
3.1220
2.6927 5.8148
8000
295.01
0.001384
0.023525 1306.0
1264.5 2570.5
1317.1
1441.6 2758.7
3.2077
2.5373 5.7450
9000
303.35
0.001418
0.020489 1350.9
1207.6 2558.5
1363.7
1379.3 2742.0
3.2866
2.3925 5.6791
10,000 311.00
0.001452
0.018028 1393.3
1151.8 2545.2
1407.8
1317.6 2725.5
3.3603
2.2556 5.6159
11,000 318.08
0.001488
0.015988 1433.9
1096.6 2530.4
1450.2
1256.1 2706.3
3.4299
2.1245 5.5544
12,000 324.68
0.001526
0.014264 1473.0
1041.3 2514.3
1491.3
1194.1 2685.4
3.4964
1.9975 5.4939
13,000 330.85
0.001566
0.012781 1511.0
985.5 2496.6
1531.4
1131.3 2662.7
3.5606
1.8730 5.4336
14,000 336.67
0.001610
0.011487 1548.4
928.7 2477.1
1571.0
1067.0 2637.9
3.6232
1.7497 5.3728
15,000 342.16
0.001657
0.010341 1585.5
870.3 2455.7
1610.3
1000.5 2610.8
3.6848
1.6261 5.3108
16,000 347.36
0.001710
0.009312 1622.6
809.4 2432.0
1649.9
931.1 2581.0
3.7461
1.5005 5.2466
(continued)
5.8 Isentropic Processes and Carnot Cycles
117
