11. When generating ORF sensors carefully check that no in-frame
STOP codons are introduced into the linker region between
GFP and Renilla luciferase.
12. At this point the competent bacteria can be aliquoted into
1.5 mL tubes (100 μL/tube) and snap-frozen in liquid N 2 .
The frozen aliquots can be stored at À70
C and used for a few
months.
13. Either YEB-RTK or YEB-RTS plates are used. Rifampicin and
tetracycline select for the strain-specific markers of C58C1.
Kanamycin selection allows for the selection of the pBIN61based (here: AGO) vectors. Spectinomycin is used to select for
the pK7WG2D- or pK7WGF2-derived plasmids (miRNA
expression vectors, sensors).
14. Expression of the AGO proteins can be detected by either HA
or FLAG antibodies. However, in our hands the 3F10 anti-HA
antibody proved to be more sensitive than the M2 FLAG
antibody. For detection of AGO proteins stripping of the
membrane is not necessary. All N. benthamiana AGOs are
>100 kDa in their size; thus, none of the bands recognized
by the GFP antibody (GFP at ~33 kDa, GFP-Renilla luciferase
at ~66 kDa) interferes with their detection.
Acknowledgments
This work was supported by the National Research, Development
and Innovation Office, Hungary (K124705).
References
1. Voinnet O (2009) Origin, biogenesis, and
activity
of
plant
microRNAs.
Cell
136:669–687
2. Martinez de Alba AE, Elvira-Matelot E, Vaucheret H (2013) Gene silencing in plants: a
diversity of pathways. Biochim Biophys Acta
1829:1300–1308
3. Bologna NG, Voinnet O (2014) The diversity,
biogenesis, and activities of endogenous silencing small RNAs in Arabidopsis. Annu Rev Plant
Biol 65:473–503
4. Yu Y, Jia T, Chen X (2017) The ‘how’ and
‘where’ of plant microRNAs. New Phytol
216:1002–1017
5. Merchante C, Stepanova AN, Alonso JM
(2017) Translation regulation in plants: an
interesting past, an exciting present and a
promising future. Plant J 90:628–653
6. Fa ´tyol K, Ludman M, Burgya ´n J (2016) Functional dissection of a plant Argonaute. Nucleic
Acids Res 44:1384–1397
7. Llave C, Xie Z, Kasschau KD, Carrington JC
(2002) Cleavage of Scarecrow-like mRNA targets directed by a class of Arabidopsis miRNA.
Science 297:2053–2056
8. Franco-Zorrilla JM, Valli A, Todesco M,
Mateos I, Puga MI, Rubio-Somoza I,
Leyva A, Weigel D, Garcia JA, Paz-Ares J
(2007) Target mimicry provides a new mechanism for regulation of microRNA activity. Nat
Genet 39:1033–1037
9. Allen E, Xie Z, Gustafson AM, Carrington JC
(2005) microRNA-directed phasing during
trans-acting siRNA biogenesis in plants. Cell
121:207–221
10. Braman J, Papworth C, Greener A (1996) Sitedirected mutagenesis using double-stranded
plasmid DNA templates. Methods Mol Biol
57:31–44
11. Bombarely A, Rosli HG, Vrebalov J, Moffett P,
Mueller LA, Martin GB (2012) A draft
genome sequence of Nicotiana benthamiana
An In Vivo Reporter System for RNA Silencing
449
