8. Pellet the germlings for 3 min at 700 Â g, remove the supernatant, and wash once with 5 mL liquid Vogel’s minimal medium.
Repeat the centrifugation and remove the supernatant.
9. Resuspend the germling pellet in 1 mL liquid Vogel’s minimal
medium, add into 30 mL liquid (55
C) Vogel’s minimal
medium top agar, and then mix by gently inverting the tube
2–3 times.
10. Distribute 5 mL top agar aliquots onto six individual
pre-warmed (30
C) Vogel’s minimal medium bottom agar
plates and wait for the top agar to solidify.
11. Incubate the plates at 30
C in the dark, and watch for
emerging colonies after 3 days.
12. Transfer emerging colonies onto fresh Vogel’s minimal
medium agar plates.
3.10 ElectroTransformation of the
12xcsy Stem-Loop
Knock-In Cassette into
N. crassa
1. Release the 12xcsy stem-loop knock-in cassette from the
pAL15.X-12xcsySL plasmid (Subheading 3.7) by PacI restriction digestion according to the manufacturer’s instructions.
2. Purify the DNA with a PCR cleanup kit according to the
manufacturer’s instructions.
3. Follow the electroporation protocol steps 3–8 as explained
above (Subheading 3.9).
4. Resuspend the germling pellet in 1 mL liquid Vogel’s minimal
medium, add to 30 mL liquid (55
C) Vogel’s minimal
medium top agar supplemented with 50 μg/mL hygromycin B,
and then mix by gently inverting the tube 2–3 times.
5. Distribute 5 mL top agar aliquots onto six individual
pre-warmed (30
C) Vogel’s minimal medium bottom agar
plates supplemented with 250 μg/mL hygromycin B and wait
for the top agar to solidify.
6. Incubate the plates at 30
C in the dark and watch for emerging
colonies after 3 days.
7. Transfer emerging colonies onto fresh Vogel’s minimal
medium agar plates supplemented with 200 μg/mL
hygromycin B.
3.11 Visualization of
Tagged mRNA in N.
crassa
1. Pre-culture a medium-size (approx. 4–5 cm diameter) fungal
colony of the final transformant strain generated in Subheading
3.10 by incubation on Vogel’s minimal medium agar supplemented with 200 μg/mL hygromycin B at 30
C for 12–14 h.
2. Use the inverted agar block method [25] to mount a
1.5 Â 1.5 cm
2 sample from the colony edge on a glass cover
slide using 15 μL of physiological salt solution as mounting
medium.
174
David Burnett et al.
