thicker than the front. To thin only the back portion of the
lamella, the stage should be tilted approximately +0.5
which
will expose the back for milling without disturbing the front
edge of the lamella [13].
16. Given the large chamber volume, poor vacuum compared to
the TEM, and cryogenic temperatures, amorphous ice buildup
is inevitable inside the cryo-FIB/SEM. This can be minimized
with proper instrument maintenance, but in our experience,
long operating times of more than 6–8 h lead to ice buildup
from the chamber and from milling redeposition. Before sample retrieval, it is recommended to perform a short 5-min
lamella cleaning step with a low FIB current for all lamellae
immediately prior to sample retrieval (Fig. 6). This step is
essentially identical to the fine milling step, but with the pattern set to skim over the surface of the lamella without removing too much material.
