Tyloxapol in 1000 mL water. The pH of the medium should be
5.95. If the pH is not around 6, either 6 M HCl or 6 M NaOH
is added to adjust the pH to 6.0. The medium is sterilized by
filtration through a 0.2 μm filter. On day of MIC set-up,
sodium nitrite is added to a final concentration of 0.1 mM.
Sodium nitrite prepared fresh as a 1 M stock in water, filtersterilized through a 0.2 μm filter, and diluted 1:10,000 in the
7H9/butyrate/Tyloxapol (pH ¼ 6) medium.
12. Sterile 60 mL square polycarbonate bottles.
13. 25 mg/mL kanamycin prepared in water and filter-sterilized.
Store at À20
C as aliquots.
14. Incubator shaker.
2.2 Preparation of
Plates for Liquid MIC
Determination
1. 96-well V-bottom polypropylene plates.
2. DMSO.
3. Drug controls made as DMSO stocks as appropriate (see Note
4) including 10 mM isoniazid stock, 1 mM rifampicin stock,
0.2 M pyrazinamide stock, and/or 10 mM linezolid stock (see
Note 5).
4. 2–20 μL Multichannel Pipette.
2.3 Preparation of
Plates for Solid
Medium MIC
Determination
1. Same materials described in Subheading 2.1.
2. 96-well, U-bottom, microtiter plates with lids.
3. 1000 μL Multichannel Pipette.
4. Sterile basins.
5. 7H11/OADC medium: Add 21 g Middlebrook 7H11 agar
base (Difco), 5 mL glycerol (add with a 6-mL sterile syringe)
with 900 mL water in a clean glass bottle containing a magnetic
stir bar. Autoclave at 15 pounds pressure at 121
C for 15 min.
Cool to 60
C in a warm water bath. Aseptically add 100 mL
oleic acid-dextrose-albumin complex (OADC). OADC consists of 8.1 g NaCl, 50 g BSA fraction V (low heavy metals),
20 g glucose, 30 mL sodium oleate solution and water to a
total volume of 1000 mL. Sodium oleate solution is made by
warming 30 mL water containing 0.19 mL 10 M NaOH to
56
C, adding 0.6 mL oleic acid, and swirling until clear. The
OADC is filter-sterilized (0.2 μm sterile filters) and stored at
4
C.
6. Heating block.
2.4 Measuring
Growth Using an
Inverted Mirror
1. 96-well, U-bottom, sterile microtiter plates with lids.
2. Sterile basins.
3. Enlarging inverted mirror.
4. Sealable plastic bags, e.g., Ziploc bags.
600
Qinglan Wang and Helena I. M. Boshoff
